Online Architectural Services -Planning Permission Drawings for 2 Storey Wraparound Exension
  • Online Architectural Services -Planning Permission Drawings for 2 Storey Wraparound Exension
  • Online Architectural Services -Planning Permission Drawings for 2 Storey Wrap Around Exension
Two Storey / One Storey Wrap Around Extension (Proposed Built Footprint < 50m ²)

Two Storey / One Storey Wrap Around Extension (Proposed Built Footprint < 50m ²)

£950.00
£950.00
Klarna Flexible payments available. Choose Klarna at checkout.

Combining both a side extension and a rear extension to create an L-shaped structure that covers two sides of a house either utilising a mix of single storey and two storey extensions or by the entirety being over two floors (subject to design constraints). This adds significant living space on both the ground and first floors and often used to create a large open-plan kitchen/living area below with new bedrooms or larger bathrooms/en-suites above.

Compulsory Package Criteria

  • Existing Built Footprint Below 100m² (Bungalows Below 150m²)
  • Proposed Built Footprint Below 50m²
  • Existing Property Not Listed or Within a Conservation Area
  • Residential Property Only (Planning Use Class C)
  • Self Measured Survey

Illustrations are used for guidance / examples only and your project specifics may vary. Please refer to our planning FAQ for further details and information regarding what is included within your package as well as answering any additional questions you may have.

What do your planning packages include?

All our planning packages include the mandatory drawings / services listed below which fulfil most Local Authority’s requirements for “standard” applications in England. However, the Planning Authority has the discretion to request additional reports which may require the involvement of a third party.

  • Purchases of Ordnance Survey Map
  • Location Plan at 1:1250 / 1:2500 scale
  • Existing and Proposed Block Plan at 1:200 or 1:500
  • Existing and Proposed Elevations at 1:100
  • Existing and Proposed Floor and Roof Plans at 1:100
  • Biodiversity Checklist Only
  • Supporting Statement
  • Application Forms and Submitting Application
  • Managing and Monitoring the Application
  • Unlimited Minor Revisions

As part of your package, we also include unlimited revisions to ensure that you are 100% satisfied with the drawings prior to submitting the application.

Our packages include all the documents required as part of a “standard” application but depending on your specific project and Local Authority requirements additional information may be required. This information is not included in our initial fee package and will be subject to an additional cost from a third-party provider arranged between yourself “the customer” and them directly although our team can assist you with this if required.
What are some of the potential additional costs during the planning stage?
  • Design and Access Statement – Required for all Listed Building applications or any, development in designated areas (e.g., Conservation Areas, World Heritage Sites)
  • Heritage Statement – Required for all Listed Building applications, development in Conservation Areas, and works affecting scheduled monuments, registered parks, designated or non-designated heritage assets including their setting and archaeological sites.
  • Flood Risk Assessment – Required for planning applications if the development is in a flood zone, you can check your site by visiting https://flood-map-for-planning.service.gov.uk/
  • Biodiversity Survey Report – Nearly all planning applications, unless exempt must submit a Biodiversity Gain Plan proving a 10% uplift in biodiversity. It is mandatory if the site and proposed work impacts protected species and habitats (rivers, woodlands).
  • Arboriculture Report - Required if there are trees affected by the proposals.
What type of application do I need?

Application types vary depending on your project but two common applications are Householder and Proposed Use Lawful Development Certificates:

  • Householder planning applications are used for proposals to alter or enlarge a single house, including works within the boundary/garden. This is commonly used if you are a homeowner wishing to complete work on your home.
  • A Lawful Development Certificate for a proposed use or development in the UK is a legal document which confirms that a planned project or change of use does not require formal planning permission. It provides legal certainty that the work is permitted development and does not require full planning permission.
Do you submit planning applications?

We submit the planning application through the Planning Portal website and will liaise with the Local Authority on your behalf throughout the process, as part of the submission we will nominate you “the customer” to pay the application fee directly. Please note that the planning application fee is not included within our packages.

Simple Process

How It Works

Choose your package, send us your details, and receive your set of professional drawings through our simplified and affordable process.

1

Choose Your Package

Select the architectural package that suits your project, with fixed pricing and no hidden costs.

2

Send Your Details

Follow our simple guides to measure your property and send us everything we need to get started.

3

Receive Your Drawings

Get your professional drawings within 10 working days or sooner, with all minor revisions included until you are ready to move forward.

Need Something More Bespoke?

If your project doesn’t quite fit within our standard packages, we’re here to help. Every home and every idea is different, and we can provide a tailored solution based on your specific requirements. Simply send us the details of your project, and our team will review everything and provide a clear, fixed-price quote - ensuring you get exactly what you need with the same simple and transparent process.
